1310nm DFB Receptacle Laser Diode (LD)

Description

Specifications 1310nm DFB Receptacle Laser Diode (LD) 1310nm 4mw SM Receptacle LD Module WSLR-1310-004m-9-DFB Min Type Max Center Wavelength@25Ўж 1290nm 1310nm 1330nm Laser Type DFB Optical Fiber Output Power (After Fiber) —- 4mW —- Fiber Specification 9um SM Fiber Threshold Current (Typ.) Ith 5mA —- 15mA Operation Current I(op) —- 35mA —- Forward Voltage 1.1V 1.6V Monitor Current 0.1mA —- —- PD Capacitance —- 10pF 15pF PD Dark Current —- —- 0.1uA Side Mode Suppression Ration 30dB 35dB —- Package Style Receptacle Isolation Optional Ferrule Type FC
