445nm Pigtailed Diode Laser with Single mode fiber

Description

Specifications 445nm Pigtailed Diode Laser with Single mode fiber SM 445nm Fiber Coupled Diode Laser WSLP-445-015m-4 Min Type Max Center Wavelength@25Ўж 440nm 445nm 460nm Spectral Width (FWHM) —- 2.0nm —- Output Power —- 15mW —- Fiber Core 4um Slope Efficiency —- 1.0mW/mA —- Monitor Current —- —- —- PD Reverse Voltage —- —- —- Fiber Connector FC/ST/SMA905 Fiber Length —- 80cm 100cm Threshold Current (Typ.) —- 30mA 60mA Operating Current (Typ.) —- 80mA 120mA Operating Voltage —- 5.5V 6.5V Package Style Coaxial
