635nm 5W Fiber Coupled LD
Description
Specifications 635nm 5W Fiber Coupled LD 635nm High power Laser Diodes WSLB-635-005-H Min. Type Max. Center Wavelength@25Ўж —- 635±,10nm —- Spectral Width (FWHM) —- 3nm —- Output Power —- 5W —- Temperature Coefficient of Wavelength —- 0.3nm / C —- Threshold Current (Typ.) —- 750mA —- Operating Current (Typ.) —- 1200mA —- Operating Voltage 35V Cooling TEC Cooling Fiber Core Diameter 600um Fiber Numerical Aperture 0.22 Fiber Length 100cm Connector Type SMA905/ST/FC Package P3 Package
