WSLD-940-001-2-PD

Description

Specifications WSLD-940-001-2-PD Min Type Max Center Wavelength@25Ўж +/-10nm 940nm +/-15nm Spectral Width (FWHM) —- 3.0nm —- Output Power —- 1W —- Monitor Current —- 700uA —- Beam Divergence (FWHM) —- 45©Ш x 10// —- Temperature Coefficient of Wavelength —- 0.3nm / C —- Slope Efficiency —- 1.0W/A —- Threshold Current (Typ.) —- 0.35A —- Operating Current (Typ.) —- 1.8A —- Operating Voltage —- 2.0V —- Package Style TO5 Emitter Size 50um
