WSLP-850-010m-PM-PD

Description

Specifications WSLP-850-010m-PM-PD Min Type Max Center Wavelength@25Ўж 830nm 850nm 855nm Spectral Width (FWHM) —- 2.0nm —- Output Power —- 10mW —- Fiber Core PM Fiber Slope Efficiency 0.7mW/mA 0.9mW/mA —- Monitor Current —- 0.1mA —- PD Reverse Voltage —- 30V —- Fiber Connector FC/ST/SMA905 Fiber Length —- 80cm 100cm Threshold Current (Typ.) —- 28mA 35mA Operating Current (Typ.) —- 85mA 110mA Operating Voltage 1.5V 1.8V 2.1V Package Style Coaxial
